Easily connect your Mac computer to an Ethernet network with the Apple USB Ethernet Adapter. Small and light, it connects to the USB 2.0 port of your Mac and provides an RJ-45 connector that supports. Download Apple Ethernet Driver for Mac to update drivers for Xserve & Macs with Apple PCI ethernet card. Operating Systems Macintosh, Mac OS X 10.3, Mac OS X 10.3.9. Additional Requirements. As most of the generic adapter comes with ASIX chip, you can download the Mac OS drivers from their website. Download and install the driver file. Now add it to the kernel extension list by running sudo. Supports IEEE 802.3az (Energy Efficient Ethernet) USB to RJ45 adapter supports Gigabit networking over USB 3.0. IEEE 802.3, 802.3u and 802.3ab (10BASE-T, 100BASE-TX, and 1000BASE-T) compatible. Crossover detection, auto-correction (Auto MDIX) and Wake-on-LAN (WOL) Powered solely through the USB.
Realtek drivers for 802.11n and 802.11ac USB-adapters. New Universal drivers for Realtek 802.11n/ac adapters - RtWlanU.kext New driver combines old drivers for 802.11n + 802.11ac adapters: RtWlanU.kext = RTL8192CU.kext + RTL8188EU.kext + RTL8192EU.kext + RTL8812AU.kext The colections download for Mac OS X.
USB-To-Ethernet Adaptors for Mac OS X
Introduction
Like many Macintosh users, I've wanted to add a second Ethernet to an iBook (iMac, or Mac Mini) to use as a server (or as a replacement for a dead Ethernet built-in). Although USB to Ethernet adaptors are cheap and plentiful, Mac OS X drivers are not. After scouring the web and talking to other Mac developers, I finally found a workable combination. The purpose of this note is to document what works since I haven't seen it widely published anywhere else. I welcome your feedback to help keep this page up-to-date.
OEM Alternative (Gigabit Ethernet but limited by USB 2.0)
Device: http://www.amazon.com/Plugable-Gigabit-Ethernet-Network-Adapter/dp/B003VSTDFGDriver: http://www.asix.com.tw/FrootAttach/driver/AX88178_Macintosh_10.4_to_10.7_Driver_v3.6.0_20111014.zip
Drivers and Supported Devices
After some research on the web, I came to realize there are two basic catagories of USB-To-Ethernet adaptors:
- USB 1.1 devices that use a Pegasus driver.
- USB 2.0 devices that use a AX8817x driver
(or its successor, the AX88772 which appeared around Aug-2005).
While there are no doubt exceptions, most of the popular low cost adaptors fall into one of these categories.
| USB Network Adaptor | Driver | |||
|---|---|---|---|---|
| Brand | Model | USB | Pegasus | AX8817X |
| 3COM | 3C460B | 1.1 | x | |
| Apple | USB Etherenet | 2.0 | ||
| Belkin | F5D5050 | 1.1 | x | |
| D-Link | DSB-650 | 1.1 | x | |
| D-Link | DSB-650TX | 1.1 | x | |
| D-Link | DUB-E100 | 2.0 | x | |
| D-Link | DUN-E100 | 2.0 | x | |
| Farallon | Netline PN796-650 | 1.1 | x | |
| Kingston | KNU101TX | 1.1 | x | |
| LinkSys | USB10TX | 1.1 | x | |
| LinkSys | USB100TX | 1.1 | x | |
| LinkSys | USB200M | 2.0 | x | |
| LinkSys | USB300M | 2.0 | x | |
| NetGear | FA120 | 2.0 | x | |
| SMC | 2208USB/ETH | 1.1 | x | |
| SMC | 2209USB/ETH | 2.0 | x | |
| TRENDnet | TU2 ETG | 2.0 | x | |
The first driver that worked for me was a Pegasus driver for Mac OS X 10.3 (Panther) developed by Daniel Sumorok. Since then I've been collaborating with Daniel to help make more drivers available. We have ported his original Pegasus driver to work on Mac OS X 10.4 (Tiger or later), and developed a USB 2.0 AX8817x driver. All are open source released under a GPL license.
You can download them from here:
| Description | File | Size | OS | Comments |
| Pegusus USB 1.1 | USBPegasusEthernet 1.0.9 | 196K | 10.3-10.5 | Universal Binary |
| AX8817x USB 2.0 | USBAx8817x 1.0.3b11 | 254K | 10.3-10.5 | Universal Binary |
| AX8817x USB 2.0 | USBAx8817x 1.0.3b14 | 315K | 10.5-10.6 | Snow Leopard 64-bit Compatible |
Each disk image includes an installer for Panther or 10.4_or_later, and a 'src' folder containing the corresponding xCode projects.
I have tested the Pegusus driver on a Belkin F5D5050 and the Ax8817x driver on a LinkSys USB200M. I am using the USB200M daily for Internet connectivity on an Intel Core Duo running Leopard.
Usb 2.0 To 10 100 Ethernet Adapter Driver Mac Os X
I found a Belkin F5D5050 USB adaptor at Buy.com for $24.30 on 3/10/2005.
I picked up a LinkSys Compact USB 2.0 Network Adaptor (USB200M) at Staples for $29.98 on 3/19/2005 .
As of 2009, the Apple USB Ethernet adaptor is probably the best choice for most Mac users. It is competively priced and offers the most hassle free driver support.
AX8817x devices are fully backward compatible with USB 1.1 host ports and are reasonably priced, so are probably the best option at this time. Pegasus based devices seem to be getting harder to find. Some USB 1.1 devices use the Realtek 8150 or Davicom DM9601 which is not supported by these drivers.
With the announcement of the MacBook Air, Apple began shipping their own USB-to-Ethernet adaptor and driver (AppleUSBEthernet).I understand Apple's USB-to-Ethernet adaptor should work on other Macs running Leopard 10.5.2 or later (Daniel Sumorok has verified this). It can also be used on systems running Mac OS X 10.3.9 or later by installing our latest USBAx8817x driver. Apple's driver is not designed to support 3rd party USB-to-Ethernet adaptors or prevoius OS versions. We have modified our own driver to take precedence over Apple's driver when it is installed, and recognize the Apple USB Ethernet Adaptor.
Latest Release Notes [18-Mar-2011]
USBAx8817x 1.0.3b14 improved compatibility with Gigabit Ethernet adaptors.
USBAx8817x 1.0.3b13 enabled Ethernet flow control.
USBAx8817x 1.0.3b12 includes a 32/64-bit Universal Binary (for 10.5 or later).
USBPegasusEthernet 1.0.9 updated to support SMC2208/ETH (ADM8513).
USBAx8817x 1.0.3b11 tuned to improve performance with some adaptors.
USBAx8817x 1.0.3b10 recognize Apple's USB-to-Ethernet Adaptor.
USBAx8817x 1.0.3b9 increases the 'probe score' returned for AX88772 devices to supercede AppleUSBEthernet.
The Tiger version was renamed to '10.4_or_later' and installs a Universal Binary that has been tested on Leopard (Mac OS X 10.5).
USBAx8817x 1.0.3b8 removes 'expected NULL' warning messages that appear in the System.log under Leopard.
USBAx8817x 1.0.3b6 and later support the new Ax88772-based DUB-E100, Airlink 101, and Belkin Gigabit USB Ethernet adaptors.
USBPegasusEthernet 1.0.8 updates the project to build properly on Leopard and supports the NetGear FA101.
Installation
Download and mount the appropriate driver disk image listed above, run the corresponding installer for Panther or 10.4_or_later, and then restart your system as suggested. The Installer will ask you to authenticate so it can place the corresponding driver in '/System/Library/Extensions/' with the correct file permisions to load as a kernel extension.
Next, plug-in your Ethernet adaptor with a live Ethernet cable attached. When you open the Network Preferences panel, it should inform you that a new port has been detected and ask if you want to enable it. Enable the new port and apply your network settings. On Leopard, the message indicating a new port has been detected may not appear, but you still need to Apply your network settings to enable the attached device for the first time.
Each driver is pre-configured to recognize a handfull of common devices. If your device does not appear to be recognized by the driver, you might have to add it to the Info.plist file, which is located inside the USBPegasusEthernet.kext or USBAx8817x.kext directory. You can use the System Profiler or USBProber tool to find the corresponding Product ID and Vendor ID.
To uninstall the driver, make sure any USB adaptors are disconnected, and then drag the corresponding driver in /System/Library/Extensions/ USBPegaususEthernet.kext or USBAx8817x.kext to the trash. You may need to authenticate that you have administrator privileges.
USB 1.1 Performance
The Pegasus chipset provides a USB 1.1 compatible implementation which could be a concern for some users. USB 1.1 runs at 1.5 Mbps (low speed) or 12 Mbps (full speed). For best performance, it's important to isolate any low speed devices on a separate bus. Mice and keyboards often run at low speed.
Usb Ethernet Adapter Driver Mac Os X 10.10
Using the Link Rate tool in IPNetMonitorX, I measured the link rate to another device on my LAN as 6 Mbps. The built-in Ethernet on my 12' PBG4 reported 44 Mpbs. When I measured the link rate to the next hop router through my cable modem, it reported 1 mbps. It didn't make any difference whether I used Ethernet built-in or the USB-To-Ethernet adaptor. Finally, I downloaded a 2.2 MB file to compare the throughput using the Monitor tool.
Both downloads took 5 seconds, but Ethernet built-in reached a peak rate of 589 KBps versus 579 kBps. Repeating the experiment several times produced similar results. Ethernet built-in might be 1-2% faster, but performance was clearly limited by the speed of my cable modem (Your Mileage May Vary).
USB 2.0 Performance
The AX8817x chip set provides a USB 2.0 compatible implementation which runs at up to 480 Mbps (high speed), so it should be possible to keep up with 100 Mbps fast ethernet as long as there are no other slower devices on the same bus. To test this I copied a 64.8 MB music file to my PBG4 laptop connected through a LinkSys USB200M Ethernet Adaptor (en3) and compared this to the same file transfer using Built-in Ethernet (en0).
Both transfers reached 10 MBps (80-90 Mbps) and took about 10 seconds. I repeated the test in the other direction.
While the USB-To-Ethernet adaptor was slightly slower, at 80 Mbps there was little noticeable difference. Files moved quickly from one system to another via 100 Mbps fast Ethernet. Copying the same file using AirPort wireless took 50-90 seconds.
Stability
While other USB-To-Ethernet drivers are reported to be buggy, I haven't encountered any stability problems to date. The adaptor turns off when the computer goes to sleep and comes back on when the computer awakes. It does not support 'Wake On LAN' at this time.
Wrap Up
This USB-To-Ethernet Adaptor combination could be an attractive solution for a Mac Mini, or old iBook used as an Internet gateway or server. I'm particularly fond of using old laptops as servers since they are compact, quiet, use little energy, and include their own battery backup.
I hope you find this information useful and welcome your comments and experience.
- Peter Sichel
Sustainable Softworks
psichel 'at' sustworks 'dot' com
Last updated 18-Mar-2011.
Many fellow Mac enthusiasts have written to thank us for these drivers (you're welcome), and some have even asked if they could contribute something to support our on going efforts. While our intent is to make these drivers freely available, we do have expenses and welcome any support. Thanks!
USB to Gigabit Ethernet adapters are especially useful for adding faster wired network capability to otherwise WiFi-only machines like the Macbook Air.
Corel draw 2019 crack nas l yap l ro. You can buy Apple’s branded 10/100 USB adapter — but price-wise, it will cost more than some gigabit adapters (like our Plugable USB Gigabit adapter). A gigabit adapter is also a nice upgrade for machines that only have a 10/100 ethernet port, but are connecting to a gigabit-capable network.
Because there’s often confusion about the rated speeds and actual throughput, especially when running 1000Mbps Ethernet over USB 2.0’s 480Mbps bus, we did some testing to establish a base line.
Usb Ethernet Adapter Driver Mac Os X 10.13
The test:
We installed the latest ASIX AX88178 Mac drivers for the Plugable Gigabit Adapter (currently v6.3.0). We used the open source network testing tool iperf running on a Mac Mini Server running 10.7.3 and a MacBook running 10.6.8. If you’d like to duplicate our tests, here’s a nice pre-compiled GUI version available here: JPerf-2.0.2.dmg. In order to isolate the adapters as completely as possible, we connected directly between two ethernet ports, set the address manually and ran iperf as both server and client in each direction. Remember that in order to get gigabit speeds, your entire network (including any routers in-between) need to be gigabit capable.
The results:
| PCI-Gigabit Ethernet | |
| USB-to-Gigabit Ethernet (Plugable USB2-E1000) | |
| USB 10/100 Ethernet |
These are low-level performance numbers (raw TCP/IP throughput). Real world throughput like copying a file over the network will be substantially lower due to transport overhead and any bottlenecks on the network or on either side of the transfer.
Using a tool like iperf and isolating the ethernet adapters to a direct connection establishes a base line for data speeds. To further identify potential networking bottlenecks, introduce one network component at a time and rerun your tests to see how the throughput is effected by the increasing complexity.
For detailed instructions on installing Mac drivers for the Plugable USB2-E1000, see Howto: Installing ASIX’s USB Gigabit Ethernet Driver on Mac OS X Lion 10.7.
We hope these numbers are useful to set performance expectations. Have any questions? We’d be happy to help. Reply here or email support@plugable.com anytime. Thanks!
